• Welded carbon steel construction
• ASME Code, Section VIII construction, stamped
and certified
• Design pressure: 250 psi @ 250°F
• Main closure: Blind flange
• Head gasket: Buna-N—other materials available
on request
• Vent connection: ¾" NPT
• Drain connection: ¾" 3000# NPT
• Inlet and outlet connections: 2" 3000# NPT
• Differential pressure gauge connection: ¼" NPT
• Interior: Epoxy coated
• Exterior: Prime coated

OPTIONS

• Air eliminator
• Air eliminator check valve
• Manual drain valve
• Pressure gauge assembly
• Pressure relief valve
• Sampling probe
• Adjustable support stand

Facet’s standard carbon steel MS Series SuperFlex
filter housings are small, economical housings for
in-line removal of solids from aviation fuels when
equipped with Facet’s M Series filter cartridges,
stacked 1, 2 or 3 high. Stainless steel construction
is available. Contact your Facet representative for
details.
